Dot Line Usb Kiosk Thermal Printer Temperature Sensor 24v For Vending Machine

Product Categories
Shenzhen Masung Technology Co. Ltd
Contact Now

Dot Line Usb Kiosk Thermal Printer Temperature Sensor 24v For Vending Machine

Brand Name : MASUNG

Model Number : W80

Certification : CE/ROHS

Place of Origin : China

MOQ : 1

Price : 170-180USD/PCS

Supply Ability : 2000 set per month

Packaging Details : carton and foam materials

Printing method : Dot line thermal printing

Printing width : 80mm(max)

Printing speed : 250mm/s(max)

Printing pattern : Inverse, underline, italic, bold, etc.

ASCII : 9*17 dots,12*24 dots

Chinese : 24*24 dots

Thermal head temperature : temperature sensor

Resolution : 576dots/line

Interface : USB/RS232

Power supply : 24V±10%

Operating system : Wins, Android, Linux, RPI

Paper type : Thermal paper roll

Contact Now

2020 New Style 80mm USB Thermal Label Printer Brand Kiosk Thermal Printer For Vending machine

Features:
Brand name thermal head & auto cutter
Ultra Highly printing speed Max 250 mm/s Unique “anti-drag” ticket system
Smart paper bezel with LEDs
Sturdy adjustable paper roll bracket (horizontal & vertical mounting)
Wide range paper thickness: from 0.06 ~ 0.2 mm

USB support USB2.0 high-speed and full-speed .Standard USB ports are implemented using the standard series B socket defined in the USB specification.

Specification:

ModelW80
Control boardEP802_3


print

Printing methodDot line thermal printing

Total dots per
line

640 dots
Printing width80mm(max)
Printing speed250mm/s(max)
Printing patternInverse, underline, italic, bold, etc.
CharacterASCII9*17 dots,12*24 dots
Chinese24*24 dots
DetectionThermal head temperaturetemperature sensor
Platen positionMechanical switch
Paper endMechanical sensor
Paper out
Paper near endReflective infrared light sensor
Paper gap
Black mark
Cutter
Paper retract
PowerWorking voltage24V±10%
Power standby≤40mA
PaperPaper width60/80/82.5mm
Paper thickness60～80μm
Paper loadAuto loading(horizontal 180°)
Paper cutterPartial/full cut
environmentOperation temperature-10～60°C(no condensation)
Operation humidity20～80%RH(40℃/85%RH)
Storage temperature-20～70°C(no condensation)
Storage humidity10～90%RH(50℃/90%RH)
Service lifeCutter service life60μm100,0000
200μm30,0000
Abrasion resistance100KM
DimensionWith 150mm paper roll, paper holder 45° upward119.30mm*89mm*86.13mm(W*D*H)
WeightAbout 1.0kg(without paper roll)
Communication interfaceSerial & USB


Application:
Sports betting terminal; video lottery machine; gaming kiosk, payment kiosks; ATM; parking system; ticket vendor, airport boarding check printer, ATB tags printer and more

Dot Line Usb Kiosk Thermal Printer Temperature Sensor 24v For Vending Machine

We highly welcome any inquiry, please feel free to contact me.
Name: Jolly Pong
Mail＆Skype: sales02@masungtek.com
Whatsapp: +86 15882275091
